Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner

China Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner supplier
Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner supplier Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner supplier Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner supplier Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner supplier

Large Image :  Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner

Product Details:

Place of Origin: CHINA
Brand Name: KING VITAL
Certification: CE
Model Number: KV50

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: one unit:plywood box with foam for express to door.package size:70x58x55cm.G.W:58kg
Delivery Time: 15 days for one unit
Payment Terms: Western Union, T/T,Visa,Master Card
Supply Ability: 1000 unit per month
Contact Now
Detailed Product Description
Product Name: Waste Diesel Oil Burner Max.output Heat: 500 000Kcal/h (20,00 000Btu/h)
Output Power: 230-460kw Oil Consumption: 35-45 Liter Per Hour
Tube Diameter: Standard Large 160mm Fuel: Waste Oil,,dirty Oil,used Oil,diesel Oil,veget Oil
Application: 0.8t Boiler,furnace,oven,wheat Dryer,reactor Feature: Large Supply,well Proven,apply For Reactor

Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner



Feature



  • KV50 with five customized nozzles,two flame stage,max reach 500 000Kcal,460kw.
  • Fully automatic.Multi usage,boiler,furnace,unsealed grain dryer,also comply with reactor.
  • Can burn all kinds of waste oil,dirty oil,used oil,clean oil,diesel oil,animal fat oil etc
  • No vulnerable parts,good to use for many years



Parameter



Model KV50
Max.output heat 500,000Kcal/h (20,00,000Btu/h)
Output power 230-460kw
Oil consumption 35-45 liter/hour
Tube diameter 160mm
Tube length 188mm
Nozzle siphon brass 5x2.0mm
Heating pipe 1.1kw
Motor power 750w
Working pressure 8 bar
Power 220v 50hz or 110v 60hz
Size 640x550x660mm
N.W 34kg
Fuel all kinds of waste oil,diesel oil
Application 0.8t boiler,furnace,oven,heater,grain dryer



Available fuel list
used engine oil/motor oil used crankcase oil used transmission oil used hydraulic oil
used synthetic oil waste machine shop cutting oil used grades #1,#3,#4 heating oils used mixed oil
used diesel oil used cooking oil used vegetable oil/animal fat oil Soybean oil
diesel oil waste car oil used tyre/rubber pyrolysis oil waste plastic oil........
✘gasoline,heavy oil,water



fire test

Portable Diesel Oil Burner , 2000000 Btu / H Waste Vegetable Oil Burner



special tips when use

  1. Our burner must work with one unit external air compressor.For kv50 model,we recommend to use 0.7-1.0cbm/min air compressor
  2. Keep the first gauge reading less than 1kg/cm2,the second one between 0.5-1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to clock the number.
  3. Oil pump will pump oil automatically,do not fill small tank by yourself.
  4. Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
  5. Please make sure no water in the fuel
  6. Do not change original setting casually,such as air flap's position.
  7. Do not touch the small oil tank,it can be very hot
  8. If you meet any trouble,please take a video for us,we will tell you how to manage.

Why choose KING VITAL burner



    -Our burner is ture waste oil system,use pc board to control,not siemens controller

    -Our burner is patented to be high efficient combustion

    -test well before leave factory

    -CE approval

    -Environment friendly,own air pollution certificate issused by China Environmental Station

    -Durable,no vulnerable parts,quality warranty for one year,spare parts for life time



About us



We are direct factory for waste oil burner&heater in China for more than15 years.We have our own machine tool workshop,forge workshop,assemble room,quality detection department,most professional enthusiastic foreign team.From manufacture to after sales services,you don't have to worry a thing.OEM,ODM are also available.

All our staff has ten years working experiences,some start their career when company founded.We are more like a family now.

You are welcome to send us an inquiry at any time,we will reply within 12 hours.Please also feel free to visit us!
