Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure

China Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure supplier
Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure supplier Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure supplier Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure supplier Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure supplier

Large Image :  Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure

Product Details:

Place of Origin: CHINA
Brand Name: KING VITAL
Certification: CE
Model Number: KV30

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: one unit:double carton box with foam for express to door.package size:58x53x42cm.G.W:25kg
Delivery Time: 7 days for one unit
Payment Terms: Western Union, T/T,Visa,Master Card
Supply Ability: 1000 unit per month
Detailed Product Description
Product Name: Fuel Oil Burner Fuel: Waste Oil,used Oil,dirty Oil,veget Oil Etc
Output Power: 210-270kw Oil Consumption: 15-21 Liter Per Hour
Max.output Heat: 300 000Kcal Working Pressure: 8bar
Application: Boiler,furnace,oven,sand Dryer,air Heater Etc Quality Warranty: One Year
High Light:

siphon nozzle oil burner

,

oil boiler burner

Boiler Dryer Furnace Use 210 - 270kw Fuel Oil Burner Waste Oil Burner KV30



Feature



  • three customized nozzle,mix with compressed air,form stable,strong flame column.
  • Fire length can be further regulated by rotating air regulator
  • Standard tube diameter,matches with various combustion chamber,such as boiler,furnace,oven,dryer,reactor etc



Parameter



Model KV30
Max.output heat 300,000Kcal/h (12,00,000Btu/h)
Output power 210-270kw
Oil consumption 15-21 liter/hour
Tube diameter 114mm
Tube length 135mm
Heating pipe 1.0kw
Motor power 180w
Nozzle siphon brass 3x2.0mm
Working pressure 8 bar
Power 220v 50hz or 110v 60hz
Size 510x455x300mm
N.W 26kg
Fuel all kinds of waste oil,diesel oil
Application 0.5t boiler,furnace,oven,heater,grain dryer



Available fuel list
used engine oil/motor oil used crankcase oil used transmission oil used hydraulic oil
used synthetic oil waste machine shop cutting oil used grades #1,#3,#4 heating oils used mixed oil
used diesel oil used cooking oil used vegetable oil/animal fat oil Soybean oil
diesel oil waste car oil used tyre/rubber pyrolysis oil waste plastic oil........
✘gasoline,heavy oil,water



kv30 fire test

Eco Friendly Residential Oil Burners , Oil Boiler Burner 8 Bar Working Pressure



special tips when use

  1. Our burner must work with one unit external air compressor.For kv30 model,we recommend to use 0.3-0.5cbm/min air compressor
  2. Keep the gauge reading less than 1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to lock the number
  3. Oil pump will pump oil automatically,do not fill small tank by yourself.
  4. Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
  5. Please make sure no water in the fuel
  6. Do not change original setting casually,such as air flap's position,distance between ignitors and flame ring.
  7. Do not touch the small oil tank,it can be very hot
  8. If you meet any trouble,please take a video for us,we will tell you how to manage.



Why choose KING VITAL burner



  • Our burner is ture waste oil system,use pc board to control,not siemens controller
  • Our burner is patented to be high efficient combustion
  • test well before leave factory
  • CE approval
  • Environment friendly,own air pollution certificate issused by China Environmental Station
  • Durable,no vulnerable parts,quality warranty for one year,spare parts for life time
