Home ProductsWaste Vegetable Oil Burner

Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour

Certification
Good quality Waste Motor Oil Burner for sales
Good quality Waste Motor Oil Burner for sales
the burner very very good,work good and save alot of money

—— Malkof

The burner that i bought from you is excellent

—— Jessie

the kv-10 unit works super at the first week.I heat 400m2 with it

—— David

today I found three customers they are ready to buy with no hestiate

—— Yasser

we bought last year,now we need more

—— Jay

I'm Online Chat Now

Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour

China Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour supplier
Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour supplier Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour supplier Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour supplier Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour supplier

Large Image :  Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour

Product Details:

Place of Origin: CHINA
Brand Name: KING VITAL
Certification: CE
Model Number: KVU30

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: double carton box or plywood box with foam
Delivery Time: 15-30 days for one unit
Payment Terms: T/T,Visa,Master Card,Western Union
Supply Ability: 1000 unit per month
Detailed Product Description
Product Name: Vertical Waste Oil Burner Max.output Heat: 300 000Kcal/h
Output Power: 210-270kw Oil Consumption: 15-21 Liter Per Hour
Tube Diameter: 114mm Fuel: Waste Oil,dirty Oil,used Oil,diesel Oil
Application: Boiler,furnace,oven Etc Feature: New Product,test Well,upward
High Light:

multi oil burner

,

vegetable oil furnace

Vertical Upward Waste Vegetable Oil Burner KVU30 210 - 270kw Intelligent



Feature



-Our burner can use all kinds of waste oil,used oil,dirty oil,clean oil,diesel oil.Have own patent to be sufficient combustion,high efficiency,friendly to environment.Multi usage,durable,fully automatic.

-The parcel includes whole oil pump&filter system etc



Parameter



Model KV03-U KV05-U KV10-U KV20-U KV30-U
Oil Consumption 2-3l/h 3-5l/h 6-8l/h 13-15l/h 15-21l/h
Output Power 14-55kw 30-60kw 80-120kw 150-200kw 210-270kw
Max.output heat 30000Kcal 50000Kcal 100 000Kcal 200 000Kcal 300 000Kcal
siphon brass nozzle 1x1.0mm 1x1.0mm 1x2.0mm 2x2.0mm 3x2.0mm
tube diameter 90mm 114mm
Application 0.1t boiler 0.1-0.2t boiler 0.3t boiler 0.4t boiler 0.5t boiler



Model KV40-U KV50-U KV60-U KV90-U
Oil consumption 30-40l/h 35-45l/h 40-60l/h 70-80l/h
Output Power 230-360kw 230-460kw 450-560kw 850-1000kw
Max.output heat 400 000Kcal 500 000Kcal 600 000Kcal 900 000Kcal
siphon brass nozzle 4x2.0mm 5x2.0mm 6x2.0mm 9x2.0mm
tube diameter 160mm
Application 0.6t boiler 0.8t boiler 1.0t boiler 1.5t boiler



Available fuel list
used engine oil/motor oil used crankcase oil used transmission oil used hydraulic oil
used synthetic oil waste machine shop cutting oil used grades #1,#3,#4 heating oils used mixed oil
used diesel oil used cooking oil used vegetable oil/animal fat oil Soybean oil
diesel oil waste car oil used tyre/rubber pyrolysis oil waste plastic oil........
✘gasoline,heavy oil,water



kv30 fire test

Vertical Upward Diesel Oil Burner , Dirty Oil Burner 15 - 21 Liter Per Hour



special tips when use



  • Our burner must work with one unit external air compressor.
  • Keep the first gauge reading less than 1kg/cm2,the second one between 0.5-1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to clock the number.
  • Oil pump will pump oil automatically,do not fill small tank by yourself.
  • Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
  • Please make sure no water in the fuel
  • Do not change original setting casually,such as air flap's position.
  • Do not touch the small oil tank,it can be very hot
  • If you meet any trouble,please take a video for us,we will tell you how to manage.



Why choose KING VITAL burner



     -Our burner is ture waste oil system,use pc board to control,not siemens controller

     -Our burner is patented to be high efficient combustion

     -test well before leave factory

     -CE approval

     -Environment friendly,own air pollution certificate issused by China Environmental Station

     -Durable,no vulnerable parts,quality warranty for one year,spare parts for life time



About us



We are direct factory for waste oil burner&heater in China for more than15 years.We have our own machine tool workshop,forge workshop,assemble room,quality detection department,most professional enthusiastic foreign team.From manufacture to after sales services,you don't have to worry a thing.OEM,ODM are also available.

All our staff has ten years working experiences,some start their career when company founded.We are more like a family now.

You are welcome to send us an inquiry at any time,we will reply within 12 hours.Please also feel free to visit us!
