Automatic Siphon Nozzle Oil Burner

China Automatic Siphon Nozzle Oil Burner supplier
Automatic Siphon Nozzle Oil Burner supplier Automatic Siphon Nozzle Oil Burner supplier Automatic Siphon Nozzle Oil Burner supplier Automatic Siphon Nozzle Oil Burner supplier

Large Image :  Automatic Siphon Nozzle Oil Burner

Product Details:

Place of Origin: CHINA
Brand Name: KING VITAL
Certification: CE
Model Number: KV05

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: one unit:double carton box with foam for express to door.package size:58x53x42cm.G.W:25kg
Delivery Time: 7 days for one unit
Payment Terms: Western Union, T/T,Visa,Master Card
Supply Ability: 1000 unit per month
Contact Now
Detailed Product Description
Product Name: Waste Motor Oil Burner Max.output Heat: 50 000Kcal/h
Output Power: 30-60kw Oil Consumption: 3-5l/h
Nozzle: Siphon Brass 1x1.0mm Fuel: All Kinds Of Dirty Oil,waste Oil,used Oil,clean Oil
Application: Boiler,furnace,air Heater,grain Dryer Etc Working Pressure: 8bar
High Light:

waste oil boiler


waste engine oil burner

30-60KW Output Power Waste Motor Oil Burner




  • all kinds of waste oil is available to burn
  • multi usage,such as boiler,furnace,oven,air heater,grain dryer
  • three safe precaution,malfunction readable
  • tested well,open parcel to use




Model KV05
Max.output heat 50,000Kcal/h (200,000Btu/h)
Output power 30-60kw
Oil consumption 3-5 liter/hour
Tube diameter 114mm
Tube length 135mm
Nozzle siphon brass 1x1.0mm
Heating pipe 1.0kw
Motor power 180w
Working pressure 8 bar (0.8mpa 116psi)
Power 220v 50hz or 110v 60hz
Burner Size(LxWxH) 510x455x300mm
N.W 25kg
Fuel all kinds of waste oil,diesel oil
Application 0.1-0.2t boiler,furnace,oven,heater,grain dryer


Available fuel list
used engine oil/motor oil used crankcase oil used transmission oil used hydraulic oil
used synthetic oil waste machine shop cutting oil used grades #1,#3,#4 heating oils used mixed oil
used diesel oil used cooking oil used vegetable oil/animal fat oil Soybean oil
diesel oil waste car oil used tyre/rubber pyrolysis oil waste plastic oil........
✘gasoline,heavy oil,water



Automatic Siphon Nozzle Oil Burner


special tips when use

  1. Our burner must work with one unit external air compressor.For kv05 model,we recommend to use 0.3-0.5cbm/min air compressor
  2. Keep the gauge reading less than 1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to lock the number
  3. Oil pump will pump oil automatically,do not fill small tank by yourself.
  4. Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
  5. Please make sure no water in the fuel
  6. Do not change original setting casually,such as air flap's position.
  7. Do not touch the small oil tank,it can be very hot
  8. If you meet any trouble,please take a video for us,we will tell you how to manage.

Why choose KING VITAL burner


     -Our burner is ture waste oil system,use pc board to control,not siemens controller

     -Our burner is patented to be high efficient combustion

     -test well before leave factory

     -CE approval

     -Environment friendly,own air pollution certificate issused by China Environmental Station

     -Durable,no vulnerable parts,quality warranty for one year,spare parts for life time
