Five Special Nozzle KV-50 Garage Waste Oill Burner Fully Automatic For Sale
Feature
KV50 with five customized nozzles,max reach 500 000Kcal,460kw.double fire stage.Fully automatic.Multi usage,such as boiler,furnace,unsealed dryer,also available to use in reactor.
Can burn all kinds of waste oil,dirty oil,used oil,also can use clean oil,diesel oil
As a direct factory for 15 years,we have long-term,large and stable supply ablility.moq is 1 unit.Spare parts for life time
Parameter
| Model |
KV50 |
| Max.output heat |
500,000Kcal/h (20,00,000Btu/h) |
| Output power |
230-460kw |
| Oil consumption |
35-45 liter/hour |
| Tube diameter |
160mm |
| Tube length |
188mm |
| Nozzle |
siphon brass 5x2.0mm |
| Heating pipe |
1.1kw |
| Motor power |
750w |
| Working pressure |
8 bar |
| Power |
220v 50hz or 110v 60hz |
| Size |
640x550x660mm |
| N.W |
34kg |
| Fuel |
all kinds of waste oil,diesel oil |
| Application |
0.8t boiler,furnace,oven,heater,grain dryer |
| ✔Available fuel list |
| used engine oil/motor oil |
used crankcase oil |
used transmission oil |
used hydraulic oil |
| used synthetic oil |
waste machine shop cutting oil |
used grades #1,#3,#4 heating oils |
used mixed oil |
| used diesel oil |
used cooking oil |
used vegetable oil/animal fat oil |
Soybean oil |
| diesel oil |
waste car oil |
used tyre/rubber pyrolysis oil |
waste plastic oil........ |
| ✘gasoline,heavy oil,water |
used in boiler
special tips when use
- Our burner must work with one unit external air compressor.For kv50 model,we recommend to use 0.7-1.0cbm/min air compressor
- Keep the first gauge reading less than 1kg/cm2,the second one between 0.5-1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to clock the number.
- Oil pump will pump oil automatically,do not fill small tank by yourself.
- Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
- Please make sure no water in the fuel
- Do not change original setting casually,such as air flap's position.
- Do not touch the small oil tank,it can be very hot
- If you meet any trouble,please take a video for us,we will tell you how to manage.
Why choose KING VITAL burner
-Our burner is ture waste oil system,use pc board to control,not siemens controller
-Our burner is patented to be high efficient combustion
-test well before leave factory
-CE approval
-Environment friendly,own air pollution certificate issused by China Environmental Station
-Durable,no vulnerable parts,quality warranty for one year,spare parts for life time
