Warehouse KVH2000 100000Kcal Portable Waste Motor Oil Heater Used Cooking Oil
Feature
KVH2000 burn all kinds of waste oil,used oil,dirty oil,as well as diesel oil,clean oil,through 304 stainless steel combustion chamber,powerful four fan system,to distritube warm air fast and efficiently.Multi usage,such as garage,workshop,factory,basement,canteen etc
Parameter
| Model |
KVH2000 |
| Heating spply area |
around 600-800sq.m |
| Max.output heat |
100,000Kcal/h (400,000Btu/h) |
| Output power |
80-120kw |
| Oil consumption |
6-8 liter/hour |
| Heating exchanger |
stainless steel combustion chamber |
| Draught fan system |
four 350mm(dia) YWF |
| Air output |
12000m3/h |
| Fan motor |
0.6kw |
| Chimney diameter |
100mm |
| Working pressure |
8 bar (0.8mpa 116psi) |
| Power |
220v 50hz or 110v 60hz |
| Size |
1900x850x1100mm |
| G.W |
300kg |
| Fuel |
all kinds of waste oil,diesel oil |
| Application |
workshop,warehouse,garage etc |
| ✔Available fuel list |
| used engine oil/motor oil |
used crankcase oil |
used transmission oil |
used hydraulic oil |
| used synthetic oil |
waste machine shop cutting oil |
used grades #1,#3,#4 heating oils |
used mixed oil |
| used diesel oil |
used cooking oil |
used vegetable oil/animal fat oil |
Soybean oil |
| diesel oil |
waste car oil |
used tyre/rubber pyrolysis oil |
waste plastic oil........ |
| ✘gasoline,heavy oil,water |
in use
special tips when use
- Our burner must work with one unit external air compressor.For kvh2000 model,we recommend to use 0.3-0.5cbm/min air compressor
- Keep the gauge reading less than 1kg/cm2.Pleae “lift↑” first then clockwise rotate slowly to open air regualtor,press down to clock the number.
- Oil pump will pump oil automatically,do not fill small tank by yourself.
- Adjust heating temperature to 90degree if use waste oil.100degree or above 100degree if use waste vegetable oil,0 degree if use diesel oil.
- Please make sure no water in the fuel
- Do not change original setting casually,such as air flap's position.
- Do not touch the small oil tank,it can be very hot
- If you meet any trouble,please take a video for us,we will tell you how to manage.
Why choose KING VITAL heater
-Our heater is ture waste oil system,use pc board to control,not siemens controller
-Our heater is patented to be high efficient combustion
-test well before leave factory
-CE approval
-Environment friendly,own air pollution certificate issused by China Environmental Station
-Durable,no vulnerable parts,quality warranty for one year,spare parts for life time
About us
We are direct factory for waste oil burner&heater in China for more than15 years.We have our own machine tool workshop,forge workshop,assemble room,quality detection department,most professional enthusiastic foreign team.From manufacture to after sales services,you don't have to worry a thing.OEM,ODM are also available.
All our staff has ten years working experiences,some start their career when company founded.We are more like a family now.
You are welcome to send us an inquiry at any time,we will reply within 12 hours.Please also feel free to visit us!
